The LDI Automatic Exposure Machine (Inline 1×2) (ACF-IM-04) is a machine used during exposure systems, part of the imaging and photo process equipment stage of PCB manufacturing. It balances precision, uptime and ease of maintenance for high-mix production.
Where the LDI Automatic Exposure Machine (Inline 1×2) Fits in PCB Manufacturing
In a PCB production line, the LDI Automatic Exposure Machine (Inline 1×2) operates in the exposure systems area of imaging and photo process equipment. Correct integration with the upstream and downstream stages is essential to overall yield, cycle time and cost per panel.
Registration alignment to hold layer-to-layer accuracy.
Recipe management and process logging via the industrial pc + vision/software.
Supplied as inline / automatic, with options for line integration.
Stainless-steel wetted parts and chemically resistant construction where the process requires it.
Safety interlocks, alarms and guarding designed for a production environment.
Typical Applications
Used to transfer circuit patterns for rigid, flex and HDI boards, including fine-feature and high-density designs.
Integration and Configuration
The LDI Automatic Exposure Machine (Inline 1×2) can be supplied as a standalone unit or integrated into a conveyorized, automated line. Panel-size handling, control software, throughput and material compatibility are configured to match your production mix. Because this is a configured-to-order system, the specification is finalized with our engineers before quotation.
Pricing
The LDI Automatic Exposure Machine (Inline 1×2) is a non-standard, configured-to-order system. Pricing starts from approximately US$28,000 for a base configuration and is finalized by quotation based on your panel size, automation level and throughput requirements.
Request a Quotation for the LDI Automatic Exposure Machine (Inline 1×2)
Tell us your requirements for the LDI Automatic Exposure Machine (Inline 1×2) (ACF-IM-04) and our engineers will respond within one business day with a tailored configuration and price.
Frequently Asked Questions
What is the LDI Automatic Exposure Machine (Inline 1x2) used for?
The LDI Automatic Exposure Machine (Inline 1x2) is used in the imaging and photo process equipment stage of PCB manufacturing, specifically for exposure systems. It is designed for consistent, production-grade results.
Which board types does the LDI Automatic Exposure Machine (Inline 1x2) support?
It supports Rigid, multilayer, HDI (flex / rigid-flex optional). The exact configuration can be tailored to your product mix.
What is the maximum panel size for the LDI Automatic Exposure Machine (Inline 1x2)?
The standard maximum panel size is 610 x 610 mm. Larger or custom panel handling can be quoted on request.
Is the LDI Automatic Exposure Machine (Inline 1x2) automated?
It is supplied as inline / automatic. It can be operated standalone or integrated into a conveyorized line with upstream and downstream handling.
What throughput can the LDI Automatic Exposure Machine (Inline 1x2) achieve?
Typical throughput is Up to 90 panels/hour, depending on panel size, recipe and board complexity.
How is the LDI Automatic Exposure Machine (Inline 1x2) controlled?
The LDI Automatic Exposure Machine (Inline 1x2) uses a industrial pc + vision/software for recipe management, process monitoring and data logging.
How do I request a quotation for the LDI Automatic Exposure Machine (Inline 1x2)?
Use the equipment finder on this page to confirm your process stage, board type and throughput, then submit the inquiry form. An engineer from acfindustry.com will respond within one business day.
