ACF-DR-03 is a X-Ray Target Drilling Machine — PCB production equipment for the mechanical drilling process within drilling and via formation equipment. It is built for process stability, throughput and operator safety on the factory floor.
X-Ray Target Drilling Machine (ACF-DR-03)
Where the X-Ray Target Drilling Machine Fits in PCB Manufacturing
In a PCB production line, the X-Ray Target Drilling Machine operates in the mechanical drilling area of drilling and via formation equipment. Correct integration with the upstream and downstream stages is essential to overall yield, cycle time and cost per panel.
Vision-based registration for accurate hole positioning.
Dust extraction and backup-board handling for clean hole walls.
Recipe management and process logging via the cnc controller.
Supplied as automatic (pc/cnc controlled), with options for line integration.
Stainless-steel wetted parts and chemically resistant construction where the process requires it.
Typical Applications
Used for through-holes and microvias in multilayer and HDI boards across consumer, automotive and telecom applications.
Integration and Configuration
The X-Ray Target Drilling Machine can be supplied as a standalone unit or integrated into a conveyorized, automated line. Panel-size handling, control software, throughput and material compatibility are configured to match your production mix. Because this is a configured-to-order system, the specification is finalized with our engineers before quotation.
Pricing
The X-Ray Target Drilling Machine is a non-standard, configured-to-order system. Pricing starts from approximately US$45,000 for a base configuration and is finalized by quotation based on your panel size, automation level and throughput requirements.
Request a Quotation for the X-Ray Target Drilling Machine
Tell us your requirements for the X-Ray Target Drilling Machine (ACF-DR-03) and our engineers will respond within one business day with a tailored configuration and price.
Frequently Asked Questions
What is the X-Ray Target Drilling Machine used for?
The X-Ray Target Drilling Machine is used in the drilling and via formation equipment stage of PCB manufacturing, specifically for mechanical drilling. It is designed for consistent, production-grade results.
Which board types does the X-Ray Target Drilling Machine support?
It supports Rigid, multilayer, HDI (flex / rigid-flex optional). The exact configuration can be tailored to your product mix.
What is the maximum panel size for the X-Ray Target Drilling Machine?
The standard maximum panel size is 610 x 610 mm. Larger or custom panel handling can be quoted on request.
Is the X-Ray Target Drilling Machine automated?
It is supplied as automatic (pc/cnc controlled). It can be operated standalone or integrated into a conveyorized line with upstream and downstream handling.
What throughput can the X-Ray Target Drilling Machine achieve?
Typical throughput is 30-60 panels/hour, depending on panel size, recipe and board complexity.
How is the X-Ray Target Drilling Machine controlled?
The X-Ray Target Drilling Machine uses a cnc controller for recipe management, process monitoring and data logging.
How do I request a quotation for the X-Ray Target Drilling Machine?
Use the equipment finder on this page to confirm your process stage, board type and throughput, then submit the inquiry form. An engineer from acfindustry.com will respond within one business day.
Accessories & Consumables
Compatible consumables and spare parts commonly supplied with drilling and via formation equipment. Contact us to add any of these to your equipment quotation.
Carbide Micro Drill Bits
Tungsten-carbide drill bits, 0.10-6.50 mm, for mechanical drilling.
Aluminum Entry Boards
Entry foils that improve hole quality and reduce burring.
Phenolic Backup Boards
Backup material protecting the drill table and hole exit.
