Used for routing, the CNC Routing Machine (Single Spindle) (ACF-PR-01) is pcb profiling and routing equipment equipment from acfindustry.com. It is configured to deliver consistent quality across rigid, multilayer and HDI boards.
CNC Routing Machine (Single Spindle) (ACF-PR-01)
Where the CNC Routing Machine (Single Spindle) Fits in PCB Manufacturing
In a PCB production line, the CNC Routing Machine (Single Spindle) operates in the routing area of pcb profiling and routing equipment. Correct integration with the upstream and downstream stages is essential to overall yield, cycle time and cost per panel.
Designed for low maintenance, fast changeover and high equipment uptime.
CNC routing with vacuum hold-down for burr-free edges.
Tool management for repeatable profile accuracy.
V-cut and separation options for panel depaneling.
Recipe management and process logging via the cnc controller.
Typical Applications
Used to profile, route and depanel boards prior to electrical test and shipment.
Integration and Configuration
The CNC Routing Machine (Single Spindle) can be supplied as a standalone unit or integrated into a conveyorized, automated line. Panel-size handling, control software, throughput and material compatibility are configured to match your production mix. Because this is a configured-to-order system, the specification is finalized with our engineers before quotation.
Pricing
The CNC Routing Machine (Single Spindle) is a non-standard, configured-to-order system. Pricing starts from approximately US$18,000 for a base configuration and is finalized by quotation based on your panel size, automation level and throughput requirements.
Request a Quotation for the CNC Routing Machine (Single Spindle)
Tell us your requirements for the CNC Routing Machine (Single Spindle) (ACF-PR-01) and our engineers will respond within one business day with a tailored configuration and price.
Frequently Asked Questions
What is the CNC Routing Machine (Single Spindle) used for?
The CNC Routing Machine (Single Spindle) is used in the pcb profiling and routing equipment stage of PCB manufacturing, specifically for routing. It is designed for consistent, production-grade results.
Which board types does the CNC Routing Machine (Single Spindle) support?
It supports Rigid, multilayer, HDI (flex / rigid-flex optional). The exact configuration can be tailored to your product mix.
What is the maximum panel size for the CNC Routing Machine (Single Spindle)?
The standard maximum panel size is 610 x 610 mm. Larger or custom panel handling can be quoted on request.
Is the CNC Routing Machine (Single Spindle) automated?
It is supplied as automatic (pc/cnc controlled). It can be operated standalone or integrated into a conveyorized line with upstream and downstream handling.
What throughput can the CNC Routing Machine (Single Spindle) achieve?
Typical throughput is 30-60 panels/hour, depending on panel size, recipe and board complexity.
How is the CNC Routing Machine (Single Spindle) controlled?
The CNC Routing Machine (Single Spindle) uses a cnc controller for recipe management, process monitoring and data logging.
How do I request a quotation for the CNC Routing Machine (Single Spindle)?
Use the equipment finder on this page to confirm your process stage, board type and throughput, then submit the inquiry form. An engineer from acfindustry.com will respond within one business day.
